About This Product
Built and manufactured for use in construction and demolition (C&D), scrap metal, general waste, building material and recycling. Can also be used for transportation of smaller plant machinery.
Key Benefits
- Built with locally sourced Australian steel
- Engineered to hold 12.5 tonne
- Full length chassis rails with middle stiffener reinforcing
- Heavy duty door hinges with grease points
- 60mm curved lifting ring
- Side hinged rear door - standard
- Ratchet door locking
- 20mm solid bar side tie down points
- Proven design
- Australia-wide delivery
Models & Dimensions
*All dimensions are in millimetres (mm) unless otherwise stated.
| Code | Capacity | Length (L) | Width (W) | Height (H) |
|---|---|---|---|---|
| HK08RL | 8 m³ | 6500 | 2400 | 850 |
| HK10RL | 10 m³ | 6500 | 2400 | 1000 |
| HK12RL | 12 m³ | 6500 | 2400 | 1150 |
| HK15RL | 15 m³ | 6500 | 2400 | 1350 |
| HK20RL | 20 m³ | 6500 | 2400 | 1750 |
| HK25RL | 25 m³ | 6500 | 2400 | 2150 |
| HK30RL | 30 m³ | 6500 | 2400 | 2500 |
| HK32RL | 32 m³ | 6500 | 2400 | 2650 |
| HK35RL | 35 m³ | 7200 | 2400 | 2650 |
| HK38RL | 38 m³ | 7200 | 2400 | 2800 |
Specifications
Steel Grade PlateAS/NZS 1594-HA250
Steel Grade StructuralAS/NZS 3679.1-300, AS1163-C350L0
Floor Thickness5 mm
Wall Thickness5 mm
Main Runner230 mm PFC
A Frame Member180 PFC
Lifting Ring60 mm
RollerØ 165 mm
FinishPrimed and painted with two (2) coats of premium alkyd enamel finish
Available Options
Retractable tarps - mesh and waterproof
Internal recessed tie down points for machinery
Two way tailgates
Side signage plates
Hardox 450 steel
Top rails capped - 8mm angle for excavator loading
Rear door stacking cut outs
Lever rear door locking
Custom size and accessories on request
